SensusRF gateway user manual
| 29/10/2019
The SNMP agent specific variables and traps available are detailed in the gateway mib file CAS-GWT-MIB.MIB
detailed in the section 19 - APPENDIX C: GATEWAY MIB FILE.
NOTE
The SNMP Traps maps the alarm notification, with the same trigger conditions described in section 11.2.9 -
ALARM.
11.2.9 ALARM
There are eight alarm notifications available in the gateway related to gateway startup, open/closed door,
external battery voltage and failure to deliver readings.
The specific alarms and their codes are:
• Alarm code 01: startup alarm, sent when the gateway start (after the clock synchronization).
• Alarm code 02: door open alarm, sent when the gateway door is opened.
• Alarm code 03: door closed alarm, sent when the gateway door is closed.
• Alarm code 04: battery voltage below limit, sent when the DC Power Supply input measurement is
below a user-defined value.
• Alarm code 05: battery voltage above limit, sent when the DC Power Supply input measurement is
above a user-defined value.
• Alarm code 06: failed to deliver last email readings alarm, sent when the readings delivery over email
fails.
• Alarm code 07: failed to deliver last ftp readings alarm, sent when the readings delivery over ftp fails.
• Alarm code 08: failed to deliver last http readings alarm, sent when the readings delivery over http
fails.
• Alarm code 10: Failed to use SD card alarm, sent when the Mobile Mode is enabled and the sdcard
is not available.
There are two alarm related configuration that can be done at the Alarm tab.
FIGURE 11-17 – ALARM
• Upper limit: Defined the limit to trigger the alarm code 05 - battery voltage above limit.
• Lower limit: Defined the limit to trigger the alarm code 04 - battery voltage below limit.
o The Upper limit cannot be smaller than the Lower limit.
