5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 942
3. If you want to view or change the units conversion factor, continue at Step 6.
4. If you want to change the currently displayed units, press the soft key: the
Units selection screen will then be displayed, as shown in Figure 25.
5. Use the and soft keys to highlight the required units, then press the
soft key to select the units. The Currently selected units screen will then be
displayed again, with the newly selected units shown.
Figure 25 - The Units selection screen
6. With the Currently selected units screen (Figure 24) shown, press the soft
key. The Units conversion factor screen will then be displayed, as shown in
Figure 26.
Figure 26 - The Units conversion factor screen
7. If you want to change the units conversion factor, press the soft key, then
edit the displayed offset as described in Section 4.10.
8. If you have a 2-measurement Multi Purpose, if necessary repeat Steps 1 to 7 of
the above procedure to change the display units for the second gas
measurement.
