Startup
Startup procedure
Operating Instructions – MOVIMOT
®
advanced
110
Advanced
drive functions
• FCB01 Output stage inhibit
• FCB02 Stop default
• FCB26 Stop at user limit
Monitoring functions
• Limit values 1
• Monitoring functions 1
• Energy-saving function
Information on the
drive unit
Device data is available via the project node.
Device data
• Device identification
• Main component
• Subcomponent
• Production label
Fault responses
Overview
• Axis module
• Power supply monitoring
• Functions
Setup
• Access rights
• Resetting device parameters.
Checklist for startup
The following checklist lists the necessary steps for complete startup.
Step Startup step Finished
1 Install the drive unit.
2 Install the MOVI-C
®
component.
3 Start MOVISUITE
®
.
4 Start up the drive train.
5 Parameterize the setpoints.
6 Parameterize the function blocks (FCBs).
7 Configure digital inputs and outputs.
8 Configure the process data (PD).
1)
9 Configure the software modules (MOVIKIT
®
).
10 Test the drive unit/application.
1) Not available with DBC designs.
