11
Technical data and dimension sheets
Dimension drawings of the drive unit
Operating Instructions – MOVIMOT
®
advanced
259
11.11 Dimension drawings of the drive unit
11.11.1 Dimension sheet notes
Scope of delivery
= Standard parts supplied by SEW‑EURODRIVE.
= Standard parts not supplied by SEW‑EURODRIVE.
Tolerances
Breather valves and cable glands
The dimension drawings always show the screw plugs. The contour dimensions may
vary slightly due to preinstalled breather valves, plug connectors or pressure compen-
sation fittings (in conjunction with the design for wet areas ).
25891936/EN – 05/2020
