Fault messages with parameterizable response
Operating Instructions – MOVIMOT
®
advanced
136
8.4 Fault messages with parameterizable response
Fault Description Index
no.
Possible fault response
Heat sink overtempera-
ture – prewarning
Here you can set the device re-
sponse when the prewarning
threshold for heat sink utilization is
exceeded (index 8336.1).
8622.2
• No response
• Warning
Positioning lag error Here you can set the device re-
sponse to a lag error (lag error win-
dow exceeded, index 8509.4).
8622.3
• No response
• Warning
• Application stop (with out-
put stage inhibit)
• Emergency stop (with out-
put stage inhibit)
• Inhibit output stage
Line phase failure Here you can set the device re-
sponse to a line phase failure (val-
ues below threshold defined by the
user, index 8351.5).
8622.4
• No response
• Warning
• Application stop (with out-
put stage inhibit)
• Emergency stop (with out-
put stage inhibit)
• Inhibit output stage
External fault Here you can set the device re-
sponse to an external fault (e.g.
triggered by terminal or control
word).
8622.5
• No response
• Warning
• Application stop (with out-
put stage inhibit)
• Emergency stop (with out-
put stage inhibit)
• Inhibit output stage
Fieldbus – timeout Here one can set how the device is
to respond to a timeout on the
EtherCAT
®
/SBus
PLUS
(timeout period,
Index 8455.3).
8622.6
• Warning
• Application stop (with out-
put stage inhibit)
• Emergency stop (with out-
put stage inhibit)
• Inhibit output stage
• Warning with self-reset
• Application stop (with out-
put stage inhibit) with self-
reset
• Emergency stop (with out-
put stage inhibit) with self-
reset
• Inhibit output stage with self
reset
