Device structure
MOVIMOT® advanced drive unit
Operating Instructions – MOVIMOT
®
advanced
15
3 Device structure
3.1 MOVIMOT
®
advanced drive unit
MOVIMOT®
advanced
drive unit
The following figure shows an example of the MOVIMOT
®
advanced drive units:
DRN80M4../BE../DBC
[1]
[2]
[4]
DRN80MK4../DBC
[1]
[2]
[3]
9007228365550731
[1]
Electronics cover
[2]
Connection box for cable glands
[3]
AC asynchronous motor
[4]
AC asynchronous motor with brake
25891936/EN – 05/2020
