Technical data and dimension sheets
Technical data of the brake
Operating Instructions – MOVIMOT
®
advanced
250
Dimension drawing of BW150‑006-T
The following figure shows the dimensions of the external braking resistor
BW150‑006-T:
75
110
174
162
7
166
65
100
<285
ø7x11
25298808587
Dimension drawing of BW100‑009-T
The following figure shows the dimensions of the external braking resistor
BW100-009-T:
75
160
174
162
7
316
65
100
<435
ø7x11
25298815755
11.5 Technical data of the brake
Also observe the information in the "DR..71-315, DRN63-315, DR2..56-80 AC Motors"
operating instructions.
25891936/EN – 05/2020
