5
Electrical installation
Installation planning taking EMC aspects into account
Operating Instructions – MOVIMOT
®
advanced
36
5 Electrical installation
INFORMATION
Adhere to the safety notes during installation.
5.1 Installation planning taking EMC aspects into account
5.1.1 Notes on arranging and routing installation components
The correct operation of decentralized inverters depends on selecting the correct
cables, providing correct grounding, and on a properly functioning equipotential bond-
ing.
Always adhere to the relevant standards.
Note the following information.
5.1.2 EMC-compliant installation
INFORMATION
This drive system is not designed for operation on a public low voltage supply system
that supplies residential areas.
This is a product with restricted availability in accordance with IEC 61800-3. This
product may cause EMC interference. In this case, it is recommended for the user to
take suitable measures.
5.1.3 Cable selection, routing and shielding
WARNING
Electric shock caused by faulty installation.
Severe or fatal injuries.
• Take the utmost care when installing the units.
• Observe the connection examples.
For more information on cable selection, routing and shielding, refer to chapter "Cable
routing and shielding".
5.1.4 Equipotential bonding
Regardless of the PE connection, it is essential that low-impedance, HF-capable
equipotential bonding is provided (see also EN60204-1 or DIN VDE0100-540):
• Provide for a connection over a wide area between the device and the mounting
plate.
• To do so, use a ground strap (HF litz wire), for example, to connect the device and
the grounding point of the system.
25891936/EN – 05/2020
