4
Mechanical installation
Installation notes
Operating Instructions – MOVIMOT
®
advanced
27
4 Mechanical installation
4.1 Installation notes
INFORMATION
Adhere to the safety notes during installation.
WARNING
Improper installation/disassembly of drive unit and mount-on components.
Serious injuries.
• Adhere to the notes about installation and disassembly.
• Before releasing shaft connections, make sure that there are no active torsional
moments present (tensions within the system).
WARNING
Risk of injury if the device starts up unintentionally, and danger of electrical voltage.
Severe or fatal injuries.
• Disconnect the device from the power supply with suitable external measures be-
fore you start working on the device and secure it against unintentional reconnec-
tion to the voltage supply.
• Secure the output shaft against rotation.
WARNING
Risk of injury caused by rapidly moving output elements.
Serious injuries.
• Disconnect the drive unit from the power supply and safeguard it against uninten-
tional power up before you start working on it.
• Equip the input and output elements (e.g. customer shaft with contact shoulder or
clamping ring, shrink disk) with a touch guard.
4.2 Required tools and resources
• Set of wrenches, set of screwdrivers, set of socket wrenches
• Torque wrench
• Mounting device
• Compensation elements (shims and spacing rings), if necessary
• Fasteners for output elements
• Lubricant (e.g. NOCO
®
fluid)
• Standard parts are not included in the delivery
25891936/EN – 05/2020
