3
Device structure
Examples for the optional nameplate "Electrical regulations UL/CE" (in preparation)
Operating Instructions – MOVIMOT
®
advanced
21
3.5 Examples for the optional nameplate "Electrical regulations UL/CE" (in
preparation)
3.6 Examples for the optional nameplate "Plug connector positions"
The nameplate is not attached to the device. If the nameplate "Plug connector posi-
tions" has been ordered, a nameplate is included in the delivery.
The following figure shows an example of the optional nameplate "Plug connector pos-
itions":
S0#:
X4142
X1203_2
X1203_1
X5504
X5505
01.1234567890.0001.20
32166306571
32533060747
25891936/EN – 05/2020
