Device structure
Example nameplate and type designation of the drive unit
Operating Instructions – MOVIMOT
®
advanced
20
4 Number of poles
4 = 4-pole motor
/
BE1 Brake
BE03 = BE03 brake
BE05 = BE05 brake
BE1 = BE1 brake
BE2 = BE2 brake
BE5 = BE5 brake
HF Brake options
HF = Manual brake release, lockable
HR = Manual brake release, automatic disengaging function
/
DI Digital motor integration
DI = Digital interface
/
DBC Communication variant
DFC = Direct Fieldbus Communication
DSI = Direct System Bus Installation
DAC = Direct AS-Interface Communication
DBC = Direct Binary Communication
EI8Z Option
EI8Z = Single-turn encoder with DDI connection
IV = Plug connector
TF = Motor protection
D11 = Switch disconnector with feedback contact
BW1= Integrated BW1 braking resistor
PE = Pressure compensation fitting electronics
AL = Metal fan
C = Canopy
RI = Reinforced winding insulation
2W = Shaft end on the motor/brakemotor
1) You can find more gear unit series in the gearmotor catalog
2) You can find more gear unit sizes in the gearmotor catalog
25891936/EN – 05/2020
