Page #252 background image
11
Technical data and dimension sheets
Line choke
Operating Instructions – MOVIMOT
®
advanced
252
11.7 Line choke
The line choke can be used as an option:
To support overvoltage protection
To smoothen the line current
For protection in the event of distorted line voltage
To limit the charging current, for example, when several inverters are connected
together in parallel on the input end (nominal current of line choke = total of nom-
inal input currents)
11.7.1 UL and cUL approval
The listed line chokes have cRUus approval independent of the drive unit.
11.7.2 Technical data
Line choke ND0070-503 ND0160-503 ND0300-503 ND0420-503
Part number 17984173 17984181 17983800 17983819
Nominal line voltage U
N
3×AC 230V – 500V 50/60Hz
Nominal current I
N
7A 16A 30A 42A
Nominal inductance 0.36mH 0.2mH 0.1mH 0.045mH
Nominal power loss 4W 9W 11W 13W
Ambient temperature ϑ
amb
-10°C – 45°C (reduction: 3% I
N
up to maximum 60°C)
Connection contacts
L1/L2/L3 – L1'/L2'/L3'
0.2–4mm
2
0.2–10mm
2
2.5–16mm
2
Tightening torque
L1/L2/L3 – L1'/L2'/L3'
0.5 – 1Nm 1.2 – 2Nm 2.5Nm
PE connection contact M4 M5
Tightening torque PE 1.5Nm 3Nm
Degree of protection IPXXB in accordance with EN60529
Mass 0.5kg 1.3kg 1.95kg 1.82kg
25891936/EN – 05/2020
