3
Device structure
Example nameplate and type designation of connection unit
Operating Instructions – MOVIMOT
®
advanced
25
3.9 Example nameplate and type designation of connection unit
3.9.1 Nameplate
The following figure gives an example of a nameplate of the connection unit. For the
structure of the type designation, refer to chapter "Type designation of the connection
unit".
Type: CUE1H-DFC-5D3-C/DI
S0#: 01.1234567890.0001.20
00 00 00 00 00 00 00 00 00
9007228465615115
3.9.2 Type designation of connection unit
The following table shows the type designation of the connection unit:
CU Product family
CU = Connection unit (motor with electronics cover)
E Hardware design
E = For MOVIMOT
®
advanced
1 Flange dimensions for relevant cover size
1 = Suitable for electronics cover size1 (with/without cooling fins)
H Fieldbus connection configuration
H = Hybrid
–
DFC Communication variant
DBC = Direct Binary Communication
DAC = Direct AS‑Interface Communication
DFC = Direct Fieldbus Communication
DSI = Direct System bus Installation
–
5 Connection voltage
5 = AC500V
D EMC variant
D = EMC filter with limit value category C3 (EN61800-3)
3 Connection type
3 = 3-phase
–
25891936/EN – 05/2020
