6
Startup
Startup requirements
Operating Instructions – MOVIMOT
®
advanced
98
6.1.1 Lifting applications
WARNING
Danger of fatal injury if the hoist falls.
Severe or fatal injuries.
• In case of products used in lifting applications, additional monitoring systems or
mechanical protection devices must be used.
WARNING
Risk from falling loads.
This can result in severe or fatal injuries.
• Do not use the function "Releasing the brake / deactivating DynaStop
®
with
FCB01" for hoist applications and applications with potentially falling loads.
• Inhibit the function via the following steps:
– Deactivate the function of the DIP switch S1/2 using the parameter Deactiva-
tion = "1" (path: Functions > Inputs/outputs > Basic device > DIP switch func-
tions > Releasing the brake / deactivating DynaStop
®
with FCB01 – enable)
– Inhibit the functions using the parameter Releasing the brake / deactivating
DynaStop
®
with FCB01 – enable = "0" (path: Functions > Drive functions >
FCB01Output stage inhibit).
Startup notes for lifting applications
INFORMATION
The recommended settings and procedures must be matched to the requirements of
the application and its safety assessment, and adjusted accordingly.
SEW‑EURODRIVE recommends the following settings and procedures for lifting ap-
plications:
• Set parameter Apply brake/activate DynaStop® in STO state (8501.3) = "1" (Yes),
see chapter "Mechanical brake in connection with STO".
• Set parameter Integrator mode (8404.9) = "0" (hold).
Path: Optimization DT1 > Set controller dynamics > Advanced settings.
6.2 Startup requirements
NOTICE
Gear unit overload.
Damage to the gear unit.
• Observe the peak torque of the gear unit when you configure the current limit and
torque limit.
• Check the current limits and torque limits and adjust them, if necessary.
Startup is only required when you need to change the factory set parameterization.
25891936/EN – 05/2020
