5
Electrical installation
Terminal assignment
Operating Instructions – MOVIMOT
®
advanced
47
5.5 Terminal assignment
INFORMATION
The terminals X3 for connecting the braking resistor can be connected to an optional,
internal braking resistor. As an alternative, you an connect an external braking resis-
tor if the power rating of this braking resistor is not sufficient.
Proceed as follows to do so:
Loosen the connections of the internal braking resistor.
Insulate and fasten the connections of the internal braking resistor. Make sure all
connections leading to other components are electrically insulated.
Connect the external braking resistor again. Observe the installation instructions
of the device and of the external braking resistor.
The following figure shows the terminal assignment of the MOVIMOT
®
advanced ..-
DBC-C drive unit:
21
1
11
23
3
13
22
X1a
2
12
1B 2B
21
1
11
23
3
13
22
X1a
2
12
1 2 3
11 12 13
X1
X31
X3
PE
21
1
11
23
3
13
22
X1a
2
12
X9
1 2 3 4
11 12 13 14
21 22 23 24
5 6
15 16
25 26
X1a
32220654603
25891936/EN – 05/2020
