Electrical installation
Terminal assignment
Operating Instructions – MOVIMOT
®
advanced
48
Assignment
Terminal No
.
Name Marking Function
X1
1)
Line termi-
nals
Without op-
tion /D11
(switch dis-
connector)
1 L1 Brown Line connection, phase L1 – IN
2 L2 Black Line connection, phase L2 – IN
3 L3 Gray Line connection, phase L3 – IN
11 L1 Brown Line connection, phase L1 – OUT
12 L2 Black Line connection, phase L2 – OUT
13 L3 Gray Line connection, phase L3 – OUT
X1a
line terminals
With option
/D11 (switch
disconnector)
1 L1 Gray Line connection, phase L1 – IN
2 L2 Gray Line connection, phase L2 – IN
3 L3 Gray Line connection, phase L3 – IN
11 L1 Gray Line connection, phase L1 – OUT
12 L2 Gray Line connection, phase L2 – OUT
13 L3 Gray Line connection, phase L3 – OUT
y
– PE – PE connection
X3
braking re-
sistor termi-
nals
1 BW – Braking resistor connection
2 BW – Braking resistor connection
25891936/EN – 05/2020
