6.11 Configuring the drive behavior at standstill (FCB 02, FCB 13, FCB 14)
The parameter Behavior at standstill defines the drive behavior in case the drive en-
able is revoked and the motor is at standstill (path: Functions > Drive functions >
FCB02 Stop default). This parameter is effective when the function blocks FCB02,
FCB13 and FCB14 are active.
The following table lists the drive behavior after motor standstill:
Index Parameter Setting of parameter
Behavior at standstill
Behavior at motor standstill
Brake Motoring
position hold
control
Effect on
the motor shaft
8563.1 Behavior at standstill
(Path: Functions >
Drive functions >
FCB02 Stop default)
Drive energized (brake
released
/ DynaStop
®
deactiva-
ted)
Brake
released
Position hold
control
active
The motor shaft is
regulated to rota-
tional speed = "0"
by the motor.
Drive not energized
(brake applied /
DynaStop
®
activated)
Brake
applied
Motor de-ener-
gized
Motor shaft is held
by brake.
Drive not energized
(without brake/
DynaStop
®
)
Brake
released
Motor de-ener-
gized
The motor shaft
can rotate freely.
