Device structure
Cable entry position
Operating Instructions – MOVIMOT
®
advanced
16
3.2 Cable entry position
The device is equipped with the following cable entries:
• Position X + 2 + 3
– X: 2 x M25 x 1.5 + 2 x M16 x 1.5 + 1 x M16 x 1.5 (only for option /PE)
– 2: 2 x M25 x 1.5 + 2 x M16 x 1.5 + 1 x M16 x 1.5 (only for option /PE)
– 3: 2×M25×1.5+2×M16×1.5
3.2.1 Overview
The following figure shows the possible cable entries of MOVIMOT® advanced:
3
X
2
32167061131
25891936/EN – 05/2020
