11.13 Dimension drawings of plug connectors in the connection box
11.13.1 Plug connectors
INFORMATION
• The following figure shows an example of the additional dimensions of the op-
tional plug connectors for a possible plug connector configuration.
• For more information, refer to chapter "Plug connector positions".
[7]
[6]
[2]
[4]
[1]
[5]
30
32
56,2
1)
/69
2)
50
1)
/56
2)
18
16
[3]
22
[6]
50
1)
/56
2)
[6]
50
1)
/56
2)
32379545483
1) "Straight" plug connector variant
2) "Right-angle" plug connector variant
[1] Optional pressure compensation
[2] M12 plug connector, female
[3] M12 plug connector, male
[4] Plug connector design Murr Elektronik, MQ15-X-Power, male
[5] Plug connector design Murr Elektronik, MQ15-X-Power, female
[6] Plug connector design TE-Intercontec Products, M23, without union nut
[7] Plug connector design TE-Intercontec Products, M23, with union nut
25891936/EN – 05/2020
