7
Operation
Binary controller
Operating Instructions – MOVIMOT
®
advanced
119
No. Configuration of the digital inputs Description
6 CW, CCW, primary frequency
• Direction of rotation positive, nega-
tive
• Speed setpoint via the primary fre-
quency input
• Fault reset
Fixed setpoint processing mode:
• Primary frequency setpoint
7.2.1 Configuration 0: User-defined configuration
Function of the di-
gital inputs
• The digital inputs can be configured freely.
• In contrast to the predefined terminal configurations 1–6, the drive unit remains in
the status "FCB 02 Stop default" once the enable signal is revoked. If you require
the status "FCB 01 Output stage inhibit", you must assign this function to a digital
input.
Configuring the
fixed setpoint pro-
cessing modes
• The fixed setpoint processing modes can be configured freely.
Fixed setpoint
processing mode
Functions of the setpoint sources
• Unipolar fixed setpoint
• Bipolar fixed setpoint
• Fixed setpoint + analog setpoint
• Fixed setpoint × analog setpoint
No function:
• Potentiometer f1
• Potentiometer f2
• DIP switch S2/2
Scaling of analog input AI1:
• Scale the speed setpoint by setting the
scaling factor of analog input AI1
• Primary frequency
• Motor potentiometer
No function:
• Potentiometer f1
• Potentiometer f2
• DIP switch S2/2
Function of analog input AI1:
• You cannot use analog input AI1 for the
speed setpoint.
Scaling of analog input AI1:
• Scale the setpoint by setting the scaling
factors of analog input AI1
• Mechanical setting elements
No function:
• Scale the speed setpoint using the scaling
parameter of analog input AI1
Scaling of analog input AI1:
• Set permanently to 0–100% of parameter
Application limit – positive/negative speed
setpoint
25891936/EN – 05/2020
