7
Operation
Function "Releasing the brake / deactivating DynaStop® with FCB 01"
Operating Instructions – MOVIMOT
®
advanced
130
• Control via the digital input
Assign the function "Releasing the brake / deactivating DynaStop
®
with
FCB01" [2] to a digital input.
[2]
18014420484362123
• Control via process data bit (not available with DBC designs)
Assign the function "Releasing the brake / deactivating DynaStop
®
with
FCB01" [3] to a process output bit.
[3]
27021619739106059
The set control signal can be used to release the brake when the function
blockFCB01 is active.
25891936/EN – 05/2020
