8
Service
Device replacement
Operating Instructions – MOVIMOT
®
advanced
203
8.8.3 Replacing the drive unit
1. Observe the safety notes.
2. Install the lifting eyes to the drive unit, see chapter "Service" > "Device replace-
ment" > "Installing the lifting eyes".
3. Disassemble the drive unit. Observe the notes in chapter "Mechanical Installation".
4. Compare the data on the nameplates of the old drive unit to the data on the name-
plates of the new drive unit.
INFORMATION
Always replace the drive unit with a drive unit that has the same properties.
In safety-related applications, replace a drive unit only with a drive unit with the same
FS logo.
5. Mount the drive unit. Observe the "Mechanical installation" chapter.
6. Remove the lifting eyes from the new drive unit. Store the lifting eyes for future
service work.
7. Perform the installation according to the "Electrical Installation" chapter.
8. Set all the controls (e.g. DIP switches, see "Startup" chapter) on the new electron-
ics cover in the same way as the controls of the previous electronics cover.
9. Remove the memory module from the old electronics cover. Insert this memory
module in the new electronics cover.
10. Place the electronics cover onto the connection box and screw it on.
11. Supply voltage to the drive.
12. Check the new drive unit for proper functioning.
25891936/EN – 05/2020
