Technical data and dimension sheets
Connection cables
Operating Instructions – MOVIMOT
®
advanced
257
Technical data
The following table shows the technical data of the signal cable:
Properties Type: HELUKABEL
®
Li9Y91YC11Y-HF
SEW EURODRIVE 150665
UL properties UL758 (AWM)
UL Style 20223 (sheath)
UL Style 10493 (insulation)
RoHS conformity Yes
Test voltage core/
core
AC 1.5kV 50Hz/1 min.
Test voltage core/
shield
AC 1.5kV 50Hz/1 min.
Operating voltage Max. AC 300V (UL)
Insulation resis-
tance
≥ 500MΩ/km
Operating tempera-
ture
-50°C to +80°C (fixed installation)
-30°C to +80°C (cable carrier)
-20°C to +60°C (cable carrier with mechanical load)
Outer diameter 15.6mm
Bending radiuses Min. 5× outer diameter (fixed installation)
Min. 8× outer diameter (cable carrier)
Bending cycles Min. 10 million
Acceleration Max. 20m/s
2
Torsion Max. ±30°/m
Chemical properties
• Oil resistance according to DIN60811-404,
HD22.10 AppendixA
• Flame retardant according to IEC60332-1-2,
UL758 cable flame test
• Halogen-free according to DINVDE0472 T.815
• Silicon-free
25891936/EN – 05/2020
