SEW DRC2 - Unit Structure; DRC Drive Unit

12
Operating Instructions – Electronic Motor DRC.-..-SNI
3
DRC drive unit
Unit Structure
3 Unit Structure
3.1 DRC drive unit
The following figure depicts drive units consisting of DRC1/DRC2 electronic motor and
R gear unit:
9007203299592075
[1] Electronics cover
[2] DRC electronic motor with connection unit
[3] Gear unit (in the figure: R gear unit)
R..DRC1-...
R..DRC2-...
[1]
[2]
[1]
[2]
[3]
[3]
