Starting up the GIO13B application option
Startup
6.6 Starting up the GIO13B application option
6.6.1 Overview of DIP switches
The following figure shows the position of the DIP switches in the GIO13B application
option:
WARNING
Burns caused by hot surfaces.
Severe injuries
• Let the units cool down before touching them.
NOTICE
Loss of the guaranteed degree of protection.
Possible damage to property.
• In disassembled condition, you have to protect the GIO13B application option from
moisture, dust or foreign particles as there are openings for DIP switches.
• Make sure that the application cover is mounted properly.
9007201137627403
ON
1234
ON
1234
ON
1234
ON
1234
ON
1234
ON
1234
S1 S2
S3
