SEW DRC2 - Technical Data of Application Options

Operating Instructions – Electronic Motor DRC.-..-SNI
163
12
Technical data of application options
Technical Data and Dimension Sheets
12.2 Technical data of application options
12.2.1 GIO12B application option
12.2.2 GIO13B application option
GIO12B application option
Degree of protection IP66
Number of inputs 4
Number of outputs 2
Connection technology M12 plug connector (A-coded, female)
Input type PLC-compatible according to EN 61131-2 (digital inputs type 3)
R
i
about 8 kΩ, sampling cycle 4 ms
Signal level +11 V to +30 V "1" = Contact closed
–3 V to +5 V "0" = Contact open
Output type PLC-compatible to EN 61131-2, interference-voltage-proof and short-circuit-proof
Sensor/actuator supply
Permitted total current
DC 24 V to EN 61131-2,
Interference voltage-proof and short-circuit-proof
250 mA (total of all connected sensors/actuators, maximum individual load: 250 mA)
Part number 1 823 801 7
GIO13B application option
Binary inputs / binary outputs
Number of binary inputs 4 (2 inputs can be used as primary frequency input)
Primary frequency input The primary frequency input function occupies a maximum of 2 digital inputs. The function is used
to evaluate frequency input signals that are provided, for example, by a distance encoder (A/B
tracks or only A track) or an external controller.
The frequency value is then converted into a digital value for further processing.
Input frequency range: 0 to 120 kHz
Signal voltage: HTL signal level
Input type PLC-compatible according to EN 61131-2 (digital inputs type 3)
R
i
about 8 kΩ, sampling cycle 4 ms
Signal level +11 V to +30 V "1" = Contact closed
–3 V to +5 V "0" = Contact open
Number of binary outputs 1
Output type Relay with change-over contact
U
max
= DC 30 V
I
min
= DC 100 mA
I
max
= DC 800 mA
Analog inputs / analog outputs
Number of analog inputs 1
Analog input type Differential input
Voltage input
V
in
= DC 0 to +10V
Resolution 10 bit
Internal resistance R
i
>10 kΩ
Current input
I
in
= DC 4 to 20 mA
Resolution 10 bit
Internal resistance R
i
= 250 Ω
Number of analog outputs 1
Analog output type Output characteristics: 4 to 20 mA
Max. output voltage: 25 V
Short-circuit-proof
Resolution 10 bit
