Overview of power section parameters
Parameters
8.3 Overview of power section parameters
8.3.1 Display values
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Power section parameters \ display values \ process values
Actual drive values
8318.0 Actual speed [rpm] 1 digit = 0.001 rpm
8501.0 User display [Text]
Output currents
8321.0 Apparent output current [%I
N
] 1 digit = 0.001 %I
N
8322.0 Active output current [%] 1 digit = 0.001 %
8326.0 Apparent output current [A] 1 digit = 0.001 A
Actual unit values
8325.0 DC link voltage [V] 1 digit = 0.001 V
8730.0 Unit utilization [%] 1 digit = 0.001 %
8327.0 Heat sink temperature [°C] 1 digit = 1 °C
Motor status
8323.0 Motor utilization [%] 1 digit = 0.001 %
9872.255 Motor temperature [°C] 1 digit = 10
−6
°C
Power section parameters \ display values \ unit status
Unit status
9702.2 Power section status [Text]
9702.7 Drive status [Text]
9702.5 Error code [Text]
10071.1 Suberror code [Text]
10404.5 Error source [Text]
Statistical data
8328.0 Operating hours [h] 1 digit = 1 min = 1/60 h
8329.0 Enable hours [h] 1 digit = 1 min = 1/60 h
8330.0 Work [kWh] 1 digit = 1Ws =
1/3600000
Power section parameters \ display values \ binary inputs
Binary inputs
8334.0, bit 0 Binary input DI00 status Fixed assignment: /controller inhibit
8334.0, bit 1 Binary input DI01 status [Bit field]
8334.0, bit 2 Binary input DI02 status [Bit field]
8334.0, bit 3 Binary input DI03 status [Bit field]
8334.0, bit 4 Binary input DI04 status [Bit field]
8335.0 Binary input DI01 function [Text]
8336.0 Binary input DI02 function [Text]
8337.0 Binary input DI03 function [Text]
8338.0 Binary input DI04 function [Text]
