Operating Instructions – Electronic Motor DRC.-..-SNI
8
Overview of parameters for application options
Parameters
8.2.2 GIO12B application option
8.2.3 GIO13B application option
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Command PCB parameters \ application option \ GIO12B
10453.1 Application option type [Text]
Application option inputs
9619.11, bit 2 Binary input DI10 [Bit field]
9619.11, bit 3 Binary input DI11 [Bit field]
9619.11, bit 4 Binary input DI12 [Bit field]
9619.11, bit 5 Binary input DI13 [Bit field]
Application option outputs
9619.112, bit 0 Binary output DO10 [Bit field]
9619.112, bit 1 Binary output DO11 [Bit field]
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Command PCB parameters \ application option \ GIO13B
Application option firmware
10453.1 Application option type [Text]
10453.16 Application option firmware [Text]
10453.17 Firmware status application option [Text]
Application option inputs
9619.11, bit 0 Binary input DI10 [Bit field]
9619.11, bit 1 Binary input DI11 [Bit field]
9619.11, bit 2 Binary input DI12 [Bit field]
9619.11, bit 3 Binary input DI13 [Bit field]
9619.26 Frequency input LFI10 [Text]
9619.36 Analog input AI10 [Text]
Application option outputs
9619.112, bit 0 Binary output DO10 [Bit field]
9619.123 Analog output AO10 [Text]
Display application option DIP switches
10453.12, bits 0 to 10 DIP switch configuration [Bit field]
DIP switch S1
10453.12, bit 0 Analog input active [Bit field]
10453.12, bit 1 Binary inputs active [Bit field]
10453.12, bit 2 Analog output active [Bit field]
10453.12, bit 3 Binary output active [Bit field]
DIP switch S2
10453.12, bit 4 Primary frequency input active [Bit field]
10453.12, bits 5 to 7 Limit frequency of primary frequency input [Bit field]
DIP switch S3
10453.12, bit 8 Frequency input mode A/B [Bit field]
10453.12, bit 9 IPOS: Download + start [Bit field]
10453.12, bit 10 Analog input: Voltage mode [Bit field]
