Installation instructions
Electrical Installation
5.2 Installation instructions
5.2.1 Connecting power supply cables
• The rated voltage and rated frequency of the DRC drive unit must correspond with
the data of the power supply system.
• Cable cross section: According to input current I
line
at rated power (see chapter
"Technical data and dimension sheets").
• Install line fuses at the beginning of the power supply cable behind the supply bus
junction. Select the fuse size according to the cable cross section.
• Use only copper cables with a minimum temperature range of 85 °C as connection
cable.
• DRC drive units are intended to be operated on voltage supply systems with
grounded star point (TN and TT systems).
5.2.2 Permitted cable cross section of terminals
Line terminals Adhere to the permitted cable cross sections for installation:
External braking
resistor terminals
Adhere to the permitted cable cross sections for installation:
Control terminals Adhere to the permitted cable cross sections for installation:
Line terminals X2 without conductor end sleeve with conductor end sleeve (with
or without insulating shroud)
Connection cross section
(mm
2
)
0.5 mm
2
– 6 mm
2
Connection cross section
(AWG)
AWG20 – AWG10
Stripping length 13 mm – 15 mm
Current carrying capacity 24 A (max. continuous current)
External braking resistor
terminals X5
without conductor end sleeve with conductor end sleeve
(with or without insulating
shroud)
Connection cross section
(mm
2
)
0.08 mm
2
– 4.0 mm
2
0.25 mm
2
– 2.5 mm
2
Connection cross section
(AWG)
AWG28 – AWG12 AWG 23 – AWG 14
Stripping length 8 mm – 9 mm
Control terminals X7 without conductor
end sleeve
with conductor end
sleeve (without
insulating shroud)
with conductor end
sleeve (with insulat-
ing shroud)
Connection cross section
(mm
2
)
0.08 mm
2
– 2.5 mm
2
0.25 mm
2
– 1.5 mm
2
Connection cross section
(AWG)
AWG 28 – AWG 14 AWG 23 – AWG 16
Stripping length 5 mm – 6 mm
Current carrying capacity 3.5 A max. continuous current
