Operating Instructions – Electronic Motor DRC.-..-SNI
5
Installation instructions
Electrical Installation
5.2.3 Terminal activation for the braking resistor
Adhere to the following sequence when activating the terminals for the braking resistor:
5.2.4 Line terminal actuation
Adhere to the following sequence when actuating the line terminals:
5.2.5 Control terminal actuation
Adhere to the following sequence when actuating the control terminals:
Terminals for the braking resistor (the following figure shows a schematic illustration)
4055861259
1.
2.
Line terminals (the following figure shows a schematic illustration)
9007203310525451
2.
1.
Control terminals (the following figure shows a schematic illustration)
9007203462751499
2.
1.
3.
