Screw fittings
Technical Data and Dimension Sheets
12.7 Screw fittings
The following tables show the screw connections available from SEW-EURODRIVE:
12.7.1 Cable glands / screw plugs
12.7.2 Screw fittings: plug connectors/pressure compensation
Type of screw fitting Figure Content Size Part number
Screw plugs
Hexagon
(made of stainless steel)
10 pcs M16 x 1.5 1 824 734 2
10 pcs M25 x 1.5 1 824 735 0
EMC cable gland
(nickel-plated brass)
10 pcs M16 x 1.5 1 820 478 3
10 pcs M25 x 1.5 1 820 480 5
EMC cable gland
(made of stainless steel)
10 pcs M16 x 1.5 1 821 636 6
10 pcs M25 x 1.5 1 821 638 2
Type of screw fitting Figure Content Size Part number
M23 plug
(made of plastic)
10 pcs M23 x 1.5 1 823 733 9
M12 plug
(made of stainless steel)
10 pcs M12 x 1.0 1 820 279 9
M12 plug
(made of stainless steel)
10 pcs M12 x 1.0 1 820 227 6
Pressure compensation fitting 1 pc M16 x 1.5 1 820 409 0
