SEW DRC2 - Description of Application Option Parameters

Operating Instructions – Electronic Motor DRC.-..-SNI
109
8
Description of application option parameters
Parameters
8.4.4 Application option
Command PCB parameters \ application option \ communication
Application option
type ID
index 10453.1
The parameter shows the designation of the application option inserted in the applica-
tion slot.
Application option
monitoring
index 10453.4
Use this parameter to set communication monitoring with the application option:
•0 = Off
•1 = On
8.5 Description of application option parameters
8.5.1 GIO12B application option
Command PCB parameters \ application option \ GIO12B
Application option
type index 10453.1
The parameter shows the designation of the application option inserted in the applica-
tion slot.
Binary input DI10
index 9619.11,
bit 1
The parameter indicates the state and function of binary input DI10 of the application
option.
Binary input DI11
index 9619.11,
bit 2
The parameter indicates the state and function of binary input DI11 on the application
option.
Binary input DI12
index 9619.11,
bit 3
The parameter indicates the state and function of binary input DI12 on the application
option.
Binary input DI13
index 9619.11,
bit 4
The parameter indicates the state and function of binary input DI13 on the application
option.
Binary output
DO10
index 9619.112,
bit 0
The parameter indicates the state and function of binary output DO10 on the application
option.
Binary output
DO11
index 9619.112,
bit 1
The parameter indicates the state and function of binary output DO11 on the application
option.
