Operating Instructions – Electronic Motor DRC.-..-SNI
17
3
Application options
Unit Structure
3.5 Application options
3.5.1 GIO12B application option
The following figure shows the GIO12B application option:
The following figure shows the position of the GIO12B nameplate:
9007201622841227
[1] Assembly/disassembly handle
[2] Retaining screws (4x)
[3] M12 plug connector for digital I/Os
18014401210968331
[1] Nameplate
[1] [2] [3]
NET
RUN
DRIVE
X4
X3
X2
X1
[1]
