Overview of parameters of the command PCB
Parameters
8 Parameters
8.1 Overview of parameters of the command PCB
8.1.1 Display values
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Command PCB parameters \ display values \ unit status
Unit status
8310.0 Operating state [Text]
DIP switch
9621.10, bit 0 Setting of DIP switch S1/1 [Bit field]
9621.10, bit 1 Setting of DIP switch S1/2 [Bit field]
9621.10, bit 2 Setting of DIP switch S1/3 [Bit field]
9621.10, bit 3 Setting of DIP switch S1/4 [Bit field]
9621.10, bit 4 Setting of DIP switch S2/1 [Bit field]
9621.10, bit 5 Setting of DIP switch S2/2 [Bit field]
9621.10, bit 6 Setting of DIP switch S2/3 [Bit field]
9621.10, bit 7 Setting of DIP switch S2/4 [Bit field]
Command PCB parameters \ display values \ binary inputs
8334.0, bit 1 Binary input DI01 status [Bit field]
8334.0, bit 2 Binary input DI02 status [Bit field]
8334.0, bit 3 Binary input DI03 status [Bit field]
8334.0, bit 4 Binary input DI04 status [Bit field]
Command PCB parameters \ display values \ unit data
Command level
– Unit series [Text]
9701.1, 9701.2,
9701.3, 9701.4, 9701.5
Unit names [Text]
9823.1, 9823.2,
9823.3, 9823.4, 9823.5
Unit signature [Text]
9701.30 Command level firmware [Text]
9701.31 Firmware status of command level [Text]
SNI interface
9701.36 SNI interface firmware [Text]
9701.37 Firmware status of SNI interface [Text]
Application option
10453.1 Application option type [Text]
Command PCB parameters \ display values \ address settings
SNI network
8995.0 MAC address [Text]
8996.0 MAC address [Text]
