Operating Instructions – Electronic Motor DRC.-..-SNI
8
Overview of parameters of the command PCB
Parameters
8.1.2 Parameters that can be changed
Storage location
Setpoints/ ramp generators
Unit functions
Application option
INFORMATION
The following parameters are stored in the DRC
motor.
If the motor is replaced, for example for service
purposes, changes made to these parameters must
be made again.
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Command PCB parameters \ setpoints/ramp generators \ setpoints
10096.35 Setpoint n_f1 0.00 – 1500.00 – 2000.00 [rpm] 1 digit = 0.001 rpm
10096.36 Setpoint n_f2 0.00 – 200.00
– 2000.00 [rpm] 1 digit = 0.001 rpm
Motor
Electronics
cover
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Command PCB parameters \ unit functions \ setup
8594.0 Factory setting • 0 = No
• 1 = Standard
• 2 = Delivery status
• 3 = Basic initialization
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Command PCB parameters \ application option \ communication
10453.1 Application option type ID [Text]
10453.4 Application option monitoring • 0 = Off
•1 = On
