Operating Instructions – Electronic Motor DRC.-..-SNI
8
Overview of power section parameters
Parameters
Virtual binary inputs
8348.0, bit 0 Binary input DI10 status [Bit field]
8348.0, bit 1 Binary input DI11 status [Bit field]
8348.0, bit 2 Binary input DI12 status [Bit field]
8348.0, bit 3 Binary input DI13 status [Bit field]
8348.0, bit 4 Binary input DI14 status [Bit field]
8348.0, bit 5 Binary input DI15 status [Bit field]
8348.0, bit 6 Binary input DI16 status [Bit field]
8348.0, bit 7 Binary input DI17 status [Bit field]
8340.0 Binary input DI10 function [Text]
8341.0 Binary input DI11 function [Text]
8342.0 Binary input DI12 function [Text]
8343.0 Binary input DI13 function [Text]
8344.0 Binary input DI14 function [Text]
8345.0 Binary input DI15 function [Text]
8346.0 Binary input DI16 function [Text]
8347.0 Binary input DI17 function [Text]
Power section parameters \ display values \ binary outputs
Virtual binary outputs
8360.0, bit 0 Binary output DO10 status [Bit field]
8360.0, bit 1 Binary output DO11 status [Bit field]
8360.0, bit 2 Binary output DO12 status [Bit field]
8360.0, bit 3 Binary output DO13 status [Bit field]
8360.0, bit 4 Binary output DO14 status [Bit field]
8360.0, bit 5 Binary output DO15 status [Bit field]
8360.0, bit 6 Binary output DO16 status [Bit field]
8360.0, bit 7 Binary output DO17 status [Bit field]
8352.0 Binary output DO10 function [Text]
8353.0 Binary output DO11 function [Text]
8354.0 Binary output DO12 function [Text]
8355.0 Binary output DO13 function [Text]
8356.0 Binary output DO14 function [Text]
8357.0 Binary output DO15 function [Text]
8358.0 Binary output DO16 function [Text]
8359.0 Binary output DO17 function [Text]
Power section parameters \ display values \ unit data
Basic unit
9701.10 Unit series [Text]
9701.11 Variant identification [Text]
9701.1 – 9701.5 Unit name [Text]
10204.2 Unit variant [Text]
9823.1 – 9823.5 Unit signature [Text]
8361.0 Nominal unit current (rms) [A] 1 digit = 0.001 A
10079.9 Motor size [Text]
9610.1 Nominal motor torque [Nm] 1 digit = 0.00001 Nm
(1E-5)
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
