Operating Instructions – Electronic Motor DRC.-..-SNI
95
8
Overview of power section parameters
Parameters
Basic unit firmware
9701.30 Basic unit firmware [Text]
9701.31 Firmware status basic unit [Text]
Power section parameters \ display values \ gear unit data
10079.3 Gear unit reduction ratio "numerator" [Text]
10079.4 Gear unit reduction ratio "denominator" [Text]
– Gear unit reduction ratio [Text]
10079.5 Number of gear unit stages (only in connection
with MOVIGEAR
®
drive units)
[Text]
Power section parameters \ display values \ fault memory 0-4 \ fault memory t-0
Error status
8366.0 Error t-0 error code [Text]
10072.1 Error t-0 suberror code [Text]
8883.0 Error t-0 internal [Text]
10404.6 Source of error t-0 [Text]
Input/output status
8371.0, bit 0..4 Binary inputs DI00 – DI04 t-0 [Bit field]
8376.0, bit 0..7 Binary inputs (virtual) DI10 – DI17 t-0 [Bit field]
8386.0, bit 0..7 Binary outputs (virtual) DO10 – DO17 t-0 [Bit field]
Actual drive values
8401.0 Actual speed t-0 [rpm] 1 digit = 0.001 rpm
8406.0 Apparent output current t-0 [%] 1 digit = 0.001 %
8411.0 Active output current t-0 [%] 1 digit = 0.001 %
8416.0 Unit utilization t-0 [%] 1 digit = 0.001 %
8441.0 Motor utilization t-0 [%] 1 digit = 0.001 %
8421.0 DC link voltage t-0 [V] 1 digit = 0.001 V
Unit status
8391.0 Power section status t-0 [Text]
8426.0 Operating hours t-0 [h] 1 digit = 1 min = 1/60 h
8431.0 Enable hours t-0 [h] 1 digit = 1 min = 1/60 h
10083.1 Work t-0 [kWh] 1 digit = 1Ws =
1/3600000
Temperatures
8396.0 Heat sink temperature t-0 [°C] 1 digit = 1 °C
10070.1 Motor temperature t-0 [°C] 1 digit = 10
−6
°C
Power section parameters \ Display values \ Error memory 0-4 \ Error memory t-1
Error status
8367.0 Error t-1 error code [Text]
10072.2 Error t-1 suberror code [Text]
8884.0 Error t-1 internal [Text]
10404.7 Source of error t-1 [Text]
Input/output status
8372.0, bit 0..4 Binary inputs DI00 – DI04 t-1 [Bit field]
8377.0, bit 0..7 Binary inputs (virtual) DI10 – DI17 t-1 [Bit field]
8387.0, bit 0..7 Binary outputs (virtual) DO10 – DO17 t-1 [Bit field]
Actual drive values
8402.0 Actual speed t-1 [rpm] 1 digit = 0.001 rpm
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
