Operating Instructions – Electronic Motor DRC.-..-SNI
8
Overview of power section parameters
Parameters
8407.0 Apparent output current t-1 [%] 1 digit = 0.001 %
8412.0 Active output current t-1 [%] 1 digit = 0.001 %
8417.0 Unit utilization t-1 [%] 1 digit = 0.001 %
8442.0 Motor utilization t-1 [%] 1 digit = 0.001 %
8422.0 DC link voltage t-1 [V] 1 digit = 0.001 V
Unit status
8392.0 Power section status t-1 [Text]
8427.0 Operating hours t-1 [h] 1 digit = 1 min = 1/60 h
8432.0 Enable hours t-1 [h] 1 digit = 1 min = 1/60 h
10083.2 Work t-1 [kWh] 1 digit = 1Ws =
1/3600000
Temperatures
8397.0 Heat sink temperature t-1 [°C] 1 digit = 1 °C
10070.2 Motor temperature t-1 [°C] 1 digit = 10
−6
°C
Power section parameters \ Display values \ Error memory 0-4 \ Error memory t-2
Error status
8368.0 Error t-2 error code [Text]
10072.3 Error t-2 suberror code [Text]
8885.0 Error t-2 internal [Text]
10404.8 Source of error t-2 [Text]
Input/output status
8373.0, bit 0..4 Binary inputs DI00 – DI04 t-2 [Bit field]
8378.0, bit 0..7 Binary inputs (virtual) DI10 – DI17 t-2 [Bit field]
8388.0, bit 0..7 Binary outputs (virtual) DO10 – DO17 t-2 [Bit field]
Actual drive values
8403.0 Actual speed t-2 [rpm] 1 digit = 0.001 rpm
8408.0 Apparent output current t-2 [%] 1 digit = 0.001 %
8413.0 Active output current t-2 [%] 1 digit = 0.001 %
8418.0 Unit utilization t-2 [%] 1 digit = 0.001 %
8443.0 Motor utilization t-2 [%] 1 digit = 0.001 %
8423.0 DC link voltage t-2 [V] 1 digit = 0.001 V
Unit status
8393.0 Power section status t-2 [Text]
8428.0 Operating hours t-2 [h] 1 digit = 1 min = 1/60 h
8433.0 Enable hours t-2 [h] 1 digit = 1 min = 1/60 h
10083.3 Work t-2 [kWh] 1 digit = 1Ws =
1/3600000
Temperatures
8398.0 Heat sink temperature t-2 [°C] 1 digit = 1 °C
10070.3 Motor temperature t-2 [°C] 1 digit = 10
−6
°C
Power section parameters \ Display values \ Error memory 0-4 \ Error memory t-3
Error status
8369.0 Error t-3 error code [Text]
10072.4 Error t-3 suberror code [Text]
8886.0 Error t-3 internal [Text]
10404.9 Source of error t-3 [Text]
Input/output status
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
