Operating Instructions – Electronic Motor DRC.-..-SNI
97
8
Overview of power section parameters
Parameters
8374.0, bit 0..4 Binary inputs DI00 – DI04 t-3 [Bit field]
8379.0, bit 0..7 Binary inputs (virtual) DI10 – DI17 t-3 [Bit field]
8389.0, bit 0..7 Binary outputs (virtual) DO10 – DO17 t-3 [Bit field]
Actual drive values
8404.0 Actual speed t-3 [rpm] 1 digit = 0.001 rpm
8409.0 Apparent output current t-3 [%] 1 digit = 0.001 %
8414.0 Active output current t-3 [%] 1 digit = 0.001 %
8419.0 Unit utilization t-3 [%] 1 digit = 0.001 %
8444.0 Motor utilization t-3 [%] 1 digit = 0.001 %
8424.0 DC link voltage t-3 [V] 1 digit = 0.001 V
Unit status
8394.0 Power section status t-3 [Text]
8429.0 Operating hours t-3 [h] 1 digit = 1 min = 1/60 h
8434.0 Enable hours t-3 [h] 1 digit = 1 min = 1/60 h
10083.4 Work t-3 [kWh] 1 digit = 1Ws =
1/3600000
Temperatures
8399.0 Heat sink temperature t-3 [°C] 1 digit = 1 °C
10070.4 Motor temperature t-3 [°C] 1 digit = 10
−6
°C
Power section parameters \ Display values \ Error memory 0-4 \ Error memory t-4
Error status
8370.0 Error t-4 error code [Text]
10072.5 Error t-4 suberror code [Text]
8887.0 Error t-4 internal [Text]
10404.10 Source of error t-4 [Text]
Input/output status
8375.0, bit 0..4 Binary inputs DI00 – DI04 t-4 [Bit field]
8380.0, bit 0..7 Binary inputs (virtual) DI10 – DI17 t-4 [Bit field]
8390.0, bit 0..7 Binary outputs (virtual) DO10 – DO17 t-4 [Bit field]
Actual drive values
8405.0 Actual speed t-4 [rpm] 1 digit = 0.001 rpm
8410.0 Apparent output current t-4 [%] 1 digit = 0.001 %
8415.0 Active output current t-4 [%] 1 digit = 0.001 %
8420.0 Unit utilization t-4 [%] 1 digit = 0.001 %
8445.0 Motor utilization t-4 [%] 1 digit = 0.001 %
8425.0 DC link voltage t-4 [V] 1 digit = 0.001 V
Unit status
8395.0 Power section status t-4 [Text]
8430.0 Operating hours t-4 [h] 1 digit = 1 min = 1/60 h
8435.0 Enable hours t-4 [h] 1 digit = 1 min = 1/60 h
10083.5 Work t-4 [kWh] 1 digit = 1Ws =
1/3600000
Temperatures
8400.0 Heat sink temperature t-4 [°C] 1 digit = 1 °C
10070.5 Motor temperature t-4 [°C] 1 digit = 10
−6
°C
Power section parameters \ display values \ process data monitor
Process data description
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
00
I
