Operating Instructions – Electronic Motor DRC.-..-SNI
8
Description of power section parameters
Parameters
Power section parameters \ display values \ process data monitor
Process data
configuration
index 8451.0
The parameter indicates the set process data word configuration.
PO1–PO3
setpoint
index 8455.0,
8456.0, 8457.0
The parameter indicates the value currently trasmitted on the process data word in
hexadecimal form.
PI1 – PI3 actual
value
index 8458.0,
8459.0, 8460.0
The parameter indicates the value currently transmitted in the process data word in
hexadecimal form.
PO setpoint Description
Index 8455.0
PO1 Setpoint
Index 8304.0
Setpoint description PO1
Index 8456.0
PO2 Setpoint
Index 8305.0
Setpoint description PO2
Index 8457.0
PO3 Setpoint
Index 8306.0
Setpoint description PO3
PO setpoint Description
Index 8458.0
PI1 Actual value
Index 8307.0
Actual value description PO1
Index 8459.0
PI2 Actual value
Index 8308.0
Actual value description PO2
Index 8460.0
PI3 Actual value
Index 8309.0
Actual value description PO3
