Description of power section parameters
Parameters
• Type 4: Limit switch left
– First search direction is CCW
– Reference position = First zero pulse or falling edge to the right of the left limit
switch.
– Machine zero = reference position + reference offset
– Reference travel should take place to zero pulse.
• Type 5: No reference travel
– Reference position = current position
– Machine zero = reference offset
• Type 6: Reference cam flush with right limit switch
– First search direction is CW
– Reference position = First zero pulse or falling edge to the left of the reference
cam
– Machine zero = reference position + reference offset
– Note: Reference cam and limit switch must be flush!
• Type 7: Reference cam flush with left limit switch
– First search direction is CCW
– Reference position = First zero pulse or falling edge to the right of the reference
cam
– Machine zero = reference position + reference offset
– Note: Reference cam and limit switch must be flush!
Referencing to
zero pulse
index 8839.0
Setting range: YES/NO.
• YES:
The drive is referenced to the zero pulse of the selected IPOS
plus®
encoder.
• NO: Reference travel takes place on the falling edge of the reference cam.
Cam distance
index 10455.0
Indicates the distance between reference cam and 0 pulse after reference travel in
increments.
