Operating Instructions – Electronic Motor DRC.-..-SNI
3
Example nameplate and type designation of electronics
Unit Structure
3.6.3 Type designation of connection unit
The following table shows the type designation of the connection unit:
3.6.4 Type designation of application options
The following table shows the type designation for the available application options:
D R C 1–5 0 3–SNI–A
DRC version
DRC installation technology
SNI = Single Line Network Installation
Connection type
3 = 3-phase (AC)
Supply voltage
50 = AC 380 – 500 V
Size
1
2
=
=
DRC 1
DRC 2
Product line
DRC = Electronic motor
G IO 1 2 B
Version
Variant
2 = 4 digital inputs + 2 digital outputs
3 = 4 digital inputs
(2 inputs can be used as primary frequency input)
+ 1 digital output
+ 1 analog input
+ 1 analog output
Version
Functionality
IO = Digital inputs/outputs
Product line
G = Option for MOVIGEAR
®
/ DRC
