SICK C4000 Fusion

Chapter 12 Operating Instructions
C4000 Palletizer Std./Adv.
C4000 Fusion
96 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8012249/YT69/2016-02-25
Subject to change without notice
Technical specifications
Minimum Typical Maximum
 Sender unit
Test input
Input voltage
12)
HIGH (active) 11 V 24 V 30 V
Input current HIGH 7 mA 10 mA 20 mA
Switching voltage LOW
(inactive)
–30 V 0 V 5 V
Input current LOW
12)
–3.5 mA 0 mA 0.5 mA
Response time to test Depending on number of beams, maximum 150 ms
Wavelength of sender 950 nm
Power consumption 1 A
Laser of the alignment aid Class 1 according to EN 60825E1 and
21 CFR 1040.10 und 1040.11 with the exception
of deviations as per Laser Notice No. 50,
June 24, 2007, optical output power  390 µW CW

typically
= 650 nm
Weight Depending on the protective field length (see
page 102)
12)
As per IEC 61131E2.
