Chapter 5 Operating instructions
S100
30 © SICK AG • Subject to change without notice 8012238/YY30/2015-02-20
Mounting
Fig. 16: Opposite mounting
Fig. 17: Offset parallel
mounting
Fig. 18: Mounting on a cross
Fig. 19: Reverse mounting,
parallel offset
Fig. 20: Reverse mounting of
two S100, with parallel offset
Min. 100 mm
Min. 100 mm
Min. 3°
Min. 3°
Min. 100 mm
