Operating instructions Chapter 11
S100
8012238/YY30/2015-02-20 © SICK AG • Subject to change without notice 47
Diagnostics
Display Output level Possible cause Rectification of the error
  
On switching outputs
On application
diagnostic output
No operating voltage,
or voltage too low
 Check the voltage
supply and activate,
if necessary.

On application
diagnostic output
No error

On application
diagnostic output
Optics cover
contaminated, no
operation
 Clean the optics
cover.

On application
diagnostic output
1 Hz
Optics cover
contaminated, still in
operation
 Clean the optics
cover.

On application
diagnostic output
4 Hz
System error  Pay attention to the
error display of the
7segment display
or carry out a
diagnostics with the
aid of the CDS-
S100.
 If necessary, switch
the device off and
back on again.
Tab. 20: LED error messages
