Addr. Parameter C Setting Options Default Setting
_:271:4 Stage 1:Dropout ratio 0.90 to 0.99 0.95
_:271:6 Stage 1:Operate delay 0.00 s to 60.00 s 3.00 s
Stage 2
_:272:1 Stage 2:Mode
•
off
•
on
•
test
off
_:272:2 Stage 2:Operate &
flt.rec. blocked
•
no
•
yes
no
_:272:3 Stage 2:Threshold 0.300 V to 200.000 V 9.000 V
_:272:4 Stage 2:Dropout ratio 0.90 to 0.99 0.95
_:272:6 Stage 2:Operate delay 0.00 s to 60.00 s 0.50 s
Information List
No. Information Data Class
(Type)
Type
General
_:2311:301 General:V2 average MV O
Group indicat.
_:4501:55 Group indicat.:Pickup ACD O
_:4501:57 Group indicat.:Operate ACT O
Stage 1
_:271:81 Stage 1:>Block stage SPS I
_:271:54 Stage 1:Inactive SPS O
_:271:52 Stage 1:Behavior ENS O
_:271:53 Stage 1:Health ENS O
_:271:55 Stage 1:Pickup ACD O
_:271:56 Stage 1:Operate delay expired ACT O
_:271:57 Stage 1:Operate ACT O
Stage 2
_:272:81 Stage 2:>Block stage SPS I
_:272:54 Stage 2:Inactive SPS O
_:272:52 Stage 2:Behavior ENS O
_:272:53 Stage 2:Health ENS O
_:272:55 Stage 2:Pickup ACD O
_:272:56 Stage 2:Operate delay expired ACT O
_:272:57 Stage 2:Operate ACT O
