4 Programming the system
4.1 Requirements
Control unit is installed and ready for operation
Maintenance PC with installed AlgoWorks EP5 is available
System-specific data files have been generated (see document e1318):
Logic elements are linked with accompanying physical devices
Parameters have been set
User texts have been defined. Possibly use the SWT11 customer text editor.
Locations of the D-Bus devices (automatic detectors, input/output modules, manual
call points) are known
4.2 Overview: Commissioning Methods for the Various Detection Systems
AnalogPLUSInteractive CollectiveMS9i
Address allocation for
individual devices
Allocation of localization structure to logical structure
Localization through address al-
location (insertion/activation) or
with device identification
 Page 27ff
Unit addresses are programmed
according to the order of installa-
tion
 Page 58ff
No addresses for the
individual devices –
instead, one address
for each detector line
 Page 63
Localized devices are allocated
to the logic elements according
to:
–the commissioning list or ground
plan
–the indexes registered with the
SmartHandy
 Page 38ff
Commissioning procedure
No allocation necessary
(no localization structure present)
Interactive devices:
Localization through address al-
location (insertion /activation)
 Page 34ff
AnalogPLUS Devices:
