Calculation of the transfer time for process image update:
K+ portion in the central controller (from row A in the following table)
+ portion in the expansion device with local connection (from row B)
+ portion in the expansion device with remote connection (from row C)
+ portion via integrated DP interface (from row D1)
+ portion via external DP interface (from row D2)
portion of consistent data via integrated DP interface (from row E1)
+ portion of consistent data via external DP interface (from row E2)
+ portion in PN/IO area for the integrated PROFINET IO interface (from row F)
+ portion for each submodule with 32 byte of consistent data for the integrated PROFINET
IO interface (from row G)
= Transfer time for process image update
The tables below show the various portions of the transfer time for a process image update
(process image transfer time). The specified times only represent "ideal values", and may be
extended accordingly by any interrupts or communication of the CPU.
Table 16- 11 Portion of the process image transfer time, CPU 410-5H
CPU 410-5H
stand-alone mode
A
*)
In the central controller
Read/write byte/word/double word
B
*)
In the expansion unit with local link
Read/write byte/word/double word
C
*)**)
In the expansion unit with remote link
Read/write byte/word/double word
D1 In the DP area for the integrated DP interface
Read byte/word/double word
D2
***)
In the DP area for the external DP interfaces
Read/write byte/word/double word
E1 Consistent data in the process image for the integrated DP
interface
E2 Consistent data in the process image for the external DP
interface (CP 443–5 extended)
Read
80 µs
100 µs
F In the PNIO area for the integrated PROFINET IO interface
Read/write for each byte/word/double word
2 µs 15 µs
G Per submodule with 32 bytes of consistent data for the
integrated PROFINET IO interface
8 µs 30 µs
*)
In the case of I/O inserted into the central controller or expansion device,
the specified value includes the execution time for the I/O module
The module data is updated with the minimum number of accesses.
(example: 8 bytes result in 2 double word accesses; 16 bytes in 4 double word accesses.)
**)
Measured with IM460-3 and IM461-3 at a link length of 100 m
***)
Measured with modules with 1 byte of user data, e.g., DI 16.
