Siemens SCALANCE X-200

Connection to PROFINET IO
7.5 Structure of the data records
SCALANCE X-200
170 Configuration Manual, 03/2015, C79000-G8976-C285-06
DomainBoundary
Specifies which multicast addresses are blocked.
MulticastBoundary
The individual bits of the DWord variables specify which of the 32 first RT_CLASS_2
multicast addresses (from 01-0E-CF-00-02-00 to 01-0E-CF-00-02-1F) is blocked.
Bit
Value
Meaning
0
1
The multicast MAC address 01-0E-CF-00-02-00 will be blocked.
0 The multicast MAC address 01-0E-CF-00-02-00 will not be blocked.
...
1
The multicast MAC address 01-0E-CF-00-02-xx will be blocked.
0 The multicast MAC address 01-0E-CF-00-02-xx will not be blocked.
31
1
The multicast MAC address 01-0E-CF-00-02-1F will be blocked.
0
The multicast MAC address 01-0E-CF-00-02-1F will not be blocked.
LinkState
Value (hexadecimal)
Meaning
0x00
Unknown
0x01
Disabled / discard
0x02
Blocked
0x03
Port listening enabled
0x04
Learn
0x05
Forward
0x06
Interrupted
0x07 – 0xFF
Reserved
MediaType
Value (hexadecimal)
Meaning
0x00
Unknown
0x01
Copper cable
0x02
Fiber-optic cable
0x00
Wireless communication
0x04 – 0xFFFFFFFF
Reserved
Note
You will find further information on the IEC data
record in IEC 61158.
