MIBs for X-200
A.2 Important private MIB variables
SCALANCE X-200
Configuration Manual, 03/2015, C79000-G8976-C285-06
175
Important private MIB variables
Important private MIB variables
The private MIB variables of the IE Switch X-200 have the following object identifier (OID):
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).
ad(4196).adProductMibs(1).simaticNet(1).iScalanceX(5).iScalanceX200(2)
snX200FaultState Read and write. Displays the error status of the device. Possible values:
• 1 No error
• 2 Error
snX200ReportFaultIndex Read only Errors are assigned an ascending index according to the order in which they
occur. This 4-byte variable specifies the index.
Contains the error message belonging to an index.
snX200FaultValue Read only This 4-byte long variable provides the current error statuses of the device bit-
snX200RmState Read only Indicates whether the redundancy manager is active or passive. Possible
values:
• 1:
The redundancy manager is passive. The IE Switch X-200 is operating as
redundancy manager and has opened the ring. In other words, the bus
with the IE Switches X-200 connected to it is operating correctly.
The "Passive" status is also shown when the redundancy manager mode
is disabled.
• 2:
The redundancy manager is active. The IE Switch X-200 is operating as
redundancy manager and has closed the ring. In other words, the line of
X-200 IE switches connected to it is interrupted (fault). The redundancy
manager switches through the connection between the ring ports and
thus restores a functioning bus configuration.
Indicates how often the redundancy manager was switched to "active".
The firmware version of the bootloader in the format major.minor.
The hardware version of the system in the format major.minor.
The serial number of the product.
The MAC address of the X-200 IE switch.
The software version of the system.
The MLFB number of the device.
